Mies style 3-seater X-frame sofa

Paul·

Mies style 3-seater X-frame sofa

This is a three-seater living room sofa that follows the furniture vocabulary of Mies van der Rohe—exposed chrome flatbar frames, a clear separation between the frame and the cushions, and leather surfaces divided by button tufting. With an overall width of 1900 mm, it features a backrest but no armrests, and its orientation is defined by X-shaped intersecting flatbar legs at both ends. While referencing the proportions and details of the Barcelona Chair/Daybed (1929), it is not a reproduction but a new design created using the same rules. The intended usage environment is a living room in an urban residence or a lounge/showroom waiting area. Since it is likely to be placed in a position visible from all sides, the back and the welds of the lower frame are finished, and the absence of armrests makes the X-shaped intersecting curves on the sides the sofa's main expression. The structure is a two-element composition consisting of independent cushions placed on an X-shaped frame made by bending and welding stainless steel flatbars.

8500100200300400mm1/10
Top ViewS : 1/10
left leather cushionback cushion0100200300400mm1/10
PlanS : 1/10
19007404001800100200300400mm1/10
Front ViewS : 1/10
0100200300400mm1/10
SectionS : 1/10

Against a person

1900740400180 2260 1830 1130 로 끝내면 뒤의 path 두 개가 통째로 주석에 먹혀 사람이 사라진다. -->

Why these numbers

  • 850mmoverall_depth

    For safe entrance through doorways and elevators, the maximum diagonal dimension of a finished sofa should not exceed approximately 2100, and the depth should not exceed 900.

  • 400mmseat_height

    The popliteal height of Korean adult men and women ranges from approximately 380 to 430, making a seat height of around 400 suitable for most people.

  • 560mmseat_depth_effective

    The seat height should allow adults to place their entire foot flat on the floor, and the effective seat depth should prevent pressure behind the knees when the back is against the backrest cushion.

  • 12degback_tilt_angle

    The original Mies furniture line features a low backrest and deep seat, designed for a reclined lounge posture rather than upright seated dining.

  • 30mmframe_bar_width

    Knoll production specification — stainless steel bar 30×10 series, mirror polish finish combined with aniline leather.

  • 10mmframe_bar_thickness

    Knoll production specification — stainless steel bar 30×10 series, mirror polish finish combined with aniline leather.
